| Design Features |
Option |
Any port configuration Inlet / Outlet possible through 4 seats |
L Port Bottom inlet to avoid intra port fluid transmission whilst in operation. |
Full or Reduce Bore |
Extended stem & pad lock capabilities provide maximum safety. |
Self adjustable gland packing |
Cavity free seals are available to reduce the possible entrapment of line media fluids between the ball and the shell. |
Renewable Seat & Seals |
Flange welded nozzles of 15NB and 20NB also available in place of screwed nozzles |
'O' ring style body seals for better joint sealing & resuable |
Standard |
ISO Mounting pad to suit actuator gear box and other hardware mountings |
Design : ASME B 16.34, BS EN ISO 17292 & API 6D |
Maintenance free live loaded double sealing |
Pressure Test : API 598 / BS EN ISO 12266-1 / API 6D |
High cycle stem packing system provides extra longer service life |
Ends : |
ASME B 16.10 (for Flange Ends only) |
Manufactuer's std. (For Threaded Ends) |
Anti-Static Device |
Ends Dimension : |
1) Threaded meets ANSI B2.1 |
Blowout proof Stem |
2) Flange meets ANSI B 16.5 |
| Application |
Mounting Pad : DIN 3337/ ISO 5211 |
Mixing and Diverting with various flow patternsaand configurations |
Material Certifications.: DIN 50.049-3 1B |
| |
Quality Systems / Certifications : ISO 9001:2008, API 6D |
